Foundation analysis and repair design
Permanent structural crack bonding
Bowing wall stabilization systems
Written coverage on all repair work
Not every crack you find in your foundation wall signals a structural problem, but every crack deserves a professional evaluation because the consequences of misclassifying a structural crack as cosmetic are serious. Our assessment process includes measuring crack width at multiple points, documenting the orientation precisely, checking for horizontal displacement at the crack face, and reviewing the soil and drainage conditions outside the wall. The result is a categorization of the crack as cosmetic, water-entry, or structural -- each with a different repair recommendation.
The repair method matched to horizontal cracks depends on the degree of deflection and the construction type of the wall. For poured concrete walls with deflection below critical thresholds, a carbon fiber strap system bonded to the wall face with structural epoxy provides a tensile reinforcement layer that counteracts the lateral earth pressure. For block walls, carbon fiber straps bonded to a plate assembly anchored into the slab and rim joist provide the same function. In both cases the straps are virtually invisible after installation and do not require interior space to accommodate them.
Polyurethane injection is specified for cracks where flexibility is a design requirement rather than structural re-bonding. Polyurethane foam expands as it cures to fill irregular voids completely, including cracks that are not perfectly planar. The cured foam remains flexible, allowing the wall to undergo minor seasonal movement without reopening the seal -- a characteristic that makes polyurethane the right choice for active cracks where temperature-driven concrete expansion and contraction may continue. Polyurethane injection is also used in wet crack conditions because the foam reacts with water during its cure, making moisture in the crack an asset rather than an obstacle to the seal.
Soil settlement beneath footings is an independent cause of foundation cracks that requires evaluation separately from the wall repair itself. When soil compresses or washes out from beneath a footing, that section of the foundation wall loses its support and the wall may develop diagonal cracks as the unsupported section deflects downward. In these cases, crack injection addresses the symptom while leaving the root cause unresolved. Our assessment includes a review of grading, drainage, and visible footing conditions to identify signs that settlement is active. Where settlement is a factor, we coordinate the repair approach to address both the crack and the soil condition that created it, preventing recurrence after the crack is sealed.
From hairline seepage cracks to structural horizontal cracking, we have the right fix.
We use two-component structural epoxy formulated for below-grade conditions and sized for the crack width encountered, ensuring complete penetration and full void fill before final curing.
We specify the appropriate polyurethane viscosity for each crack condition, using slower-reacting formulations for complete penetration into deep, narrow cracks and faster-reacting types for active water flow.
We calculate strap spacing and quantity based on the measured deflection, wall height, and soil pressure conditions at each job so the reinforcement is engineered for your specific wall rather than generically applied.
Where bowing wall deflection exceeds the threshold for carbon fiber repair alone, a wall anchor system provides mechanical resistance by connecting the deflecting wall to stable soil beyond the active failure zone through a tension rod and plate assembly.
Severe stair-step cracking that indicates ongoing settlement is evaluated for root cause before repair so we are not sealing a crack that will reopen as the movement continues.
The joint where a poured concrete wall meets the footing is a construction cold joint that is prone to opening as the wall and footing settle and move at slightly different rates, creating a direct water pathway into the basement.
We measure every crack for width, orientation, and displacement, review the soil and drainage context, and classify each crack by type and severity before recommending any repair method.
Written scope defines every material, method, and warranty term before you approve any work so there are no surprises on the invoice.
Our certified crew executes the repair to specification, maintaining injection pressure logs and documenting material volumes consumed to verify complete crack penetration.
Your warranty packet includes installation photos, crack condition documentation, and recommended monitoring intervals for any cracks assessed as stable but worth tracking.
We had a 14-foot horizontal crack in our block wall that two other companies dismissed as not serious. JCB Waterproofing and Construction came in, took actual measurements, and explained exactly why it needed carbon fiber straps immediately. The repair looks clean and the wall has not moved since.
I was told by two contractors that my diagonal cracks were just cosmetic. JCB Waterproofing and Construction measured the crack width at three points and showed me they were widening. The epoxy injection repair was completed cleanly and the cracks have been stable for over a year.
I appreciated that they did not try to upsell me on a full drain system when crack injection was the right fix for my situation. They solved the actual problem and the repair has held completely.
Don't let a small crack become a structural emergency. Contact JCB Waterproofing and Construction for a written evaluation and quote in Coldwater, OH.
Call +1-866-476-1348 Now
